Amplifier, 60 Watts AC & 12V DC Operation

Amplifier, 60 Watts AC & 12V DC Operation

Product Details:

X

Product Description

SSB-60EM is compact, portable and ideal for most general purpose applications. This amplifier is ideal for use in small sized houses of worship and other similar applications. Since it also operates on 12V Car Battery it is convenient for areas without continuous mains power supply

Features:
  • 4 Mic & 1 Aux Inputs
  • Preamplifier Output for connecting to a Booster Amplifier and for recording the programme.
  • Instant transfer to DC power (Car Battery) if AC power fails.
  • Cut type Bass & Treble Controls.
Specifications:

ZONE-A ZONE-B
POWER OUTPUT 90W RMS Max., 65W RMS at 10% THD
60W RMS at 5% THD, 50W RMS at 2% THD
OUTPUT REGULATIONS ≤2 dB, no load to full load at 1kHz
INPUT CHANNELS 4 x Mic 0.65mV/4.7kΩ
1 x Aux 100mV/470k
Ω
FREQUENCY RESPONSE 50-15,000Hz ±3dB
SIGNAL TO NOISE RATIO 60dB
TONE CONTROLS Bass: -10dB at 100Hz, Treble: -10dB at 10kHz
OUTPUTS Preamp 200mV/600Ω
SPEAKER OUTPUTS 4Ω, 8Ω, 16Ω & 100V
POWER SUPPLY AC: 220-240V 50/60Hz DC: 12V (12V Car Battery)
POWER CONSUMPTION AC: 160VA DC: 3A
DIMENSIONS W350 x H120 x D265 mm
WEIGHT 7.0kg
