PA Amplifier, 80 Watts AC & 12V DC Operation

PA Amplifier, 80 Watts AC & 12V DC Operation

Product Details:

X

Product Description

ATR model SSB-80EM is 80 watts PA Amplifier. Being operable on 12V Car Battery, it is ideal for temporary outdoor installations. Rugged construction, conservatively rated components and protection against operational mistakes ensure long & trouble free service.

Features:
  • 5 Mic & 2 Aux Inputs.
  • Preamplifier Output for connecting to a Booster Amplifier and for recording the programme.
  • Cut type Bass & Treble controls.
  • Instant transfer to DC power (Car Battery) if AC power fails.
Specifications:

SSB-80EM
POWER OUTPUT 110W RMS Max., 80W RMS at 10% THD
75W RMS at 5% THD, 60W RMS at 2% THD
OUTPUT REGULATIONS Ω2 dB, no load to full load at 1kHz
INPUT CHANNELS 5 x Mic 0.65mV/4.7kΩ, 2 x Aux 100mV/470kΩ
FREQUENCY RESPONSE 65-15,000Hz ±3dB
SIGNAL TO NOISE RATIO 60dB
TONE CONTROLS Bass: -10dB at 100Hz, Treble: -10dB at 10kHz
OUTPUTS Preamp 200mV/600Ω
SPEAKER OUTPUTS 4Ω, 8Ω, 16Ω, 70V & 100V
POWER SUPPLY AC: 220-240V 50/60Hz DC: 12V (12V Car Battery)
POWER CONSUMPTION AC: 180VA DC: 3A
DIMENSIONS W355 x H133 x D285 mm
WEIGHT 8.5kg
