Amplifier, 45 Watts AC & 12V DC Operation

Amplifier, 45 Watts AC & 12V DC Operation

Product Details:

X

Product Description

SSB-45 is compact, portable and ideal for most general purpose applications. This amplifier is ideal for use in small sized houses of worship and other similar applications. Since it also operate on 12V Car Battery, it is convenient for areas without continuous mains power supply.

Features:
  • 3 Mic & 1 Aux Inputs.
  • Preamplifier Output for connecting to a Booster Amplifier and for recording the programme.
  • Instant transfer to DC power (Car Battery) if AC power fails.
  • Cut type Bass & Treble Controls.
Specifications:

ZONE-A ZONE-B
POWER OUTPUT 64W RMS Max., 45W RMS at 10% THD
40W RMS at 5% THD, 30W RMS at 2% THD
OUTPUT REGULATIONS ≤2 dB, no load to full load at 1kHz
INPUT CHANNELS 3 x Mic 0.65mV/4.7kΩ,
1 x Aux 100mV/470kΩ
FREQUENCY RESPONSE 100-15,000Hz ±3dB
SIGNAL TO NOISE RATIO 60dB
TONE CONTROLS Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz
OUTPUTS Preamp 200mV/600Ω
SPEAKER OUTPUTS 4Ω, 8Ω, 16Ω & 100V
POWER SUPPLY AC: 220-240V 50/60Hz DC: 12V (12V Car Battery)
POWER CONSUMPTION AC: 110VA DC: 2A
DIMENSIONS W280 x H120 x D270 mm
WEIGHT 4.8kg
